Video content details：

ASEMI brand MBR60100PT,TO-247/3P series，Environmentally friendly imported chip, export quality, Mikron chip, environmentally friendly and reliable, high stability, highly consistent product dispersion. This product original packing genuine product, the quality guarantee high stability and the reliability.Welcome to apply for free sample test.

Video content details：

ASEMI brand MBR60200PT,TO-247/3P series，Environmentally friendly imported chip, export quality, Mikron chip, environmentally friendly and reliable, high stability, highly consistent product dispersion. This product original packing genuine product, the quality guarantee high stability and the reliability.Welcome to apply for free sample test.

DETAIL

Schottky diode MBR60100PT

electrical parameters 60A100V

Laser marking, fadeless, vinyl material; Epoxy resin material, good encapsulation stability

The pin is oxygen-free copper with good resistance to bending, oxidation and conduction

360/box,30pcs/tube,Environmental protection and anti-static PE pipe, kraft paper box, anti-static, easy to preserve, recyclable.

MBR60200PT: 1800/CTN Material: kraft paper, resistant to pressure, abrasion and impact

Packing：360/box Carton: environmental protection, sealed material Size:56.4*15.0*4.1cm

DESVRIPTION

GREEN LASER PRINTER

●laser marking, non-fading, to solve the ink screen printing easy fade

●high production efficiency of laser marking, short delivery time, solve the problem of long delivery time and low efficiency of ink printing

ADVANCED PLASTIC PACKAGING

●disposable injection molding with epoxy resin material

●good flame retardant performance, high strength, high temperature resistance

PURE OXYGEN-FREE COPPER PINS

●oxygen free copper, excellent electrical conductivity

●pin thickening design, thickness up to 0.25mm, can work for a long time without heating

●the LOGO of the original "ASEMI" brand in Taiwan

●A = advanced

●SEMI = semiconductor

●the figure shows the symbol of common cathod diode

●both ends are input current and the middle is output current in general

●there are two diodes integrated inside

PRODUCT ANALYSIS

●[MBR60200PT] represents the complete model of the product

●[MBR stands for the  schottky diode

●[60] means its forward current is 60a

●[200] represents its reverse withstand voltage is 200V

●[PT] represents it's belong to TO-247 package

SIZE

Body Height ：

19.9mm

Body Width ：

15.6mm

Lead Length ：

20.0mm

Positioning Hole Height：

17.8mm

Body Thickness：

4.80mm

Lead Spacing：

5.45mm

Lead Thickness：

0.62mm

PROCESS

Product

stability

Product stability

Adopt Taiwan GPP wave chip, the product continues to be stable

Accurate product quantity

Accurate product quantity

Strict packaging inspection procedures to ensure that the product quantity is accurate, packaging without damage

One-step injection molding

One-step injection molding

Automated equipment supports injection molding in one step

Passed 6 quality checks

Passed 6 quality
checks

12 parameters such as Vb, Io, If, Vf, and Ir are detected through 6 channels, and ΔV is controlled within 80V to improve the consistency and reliability of 4 chips.

Perfect interpersonal interaction

Perfect interpersonal interaction

Reinforcement, cutting, separation, perfect interpersonal interaction process

PRODUCT PK

chip marking method pin testing equipment

ASEMI adopts 150mil high-quality large chip, with good parameter consistency and stable and efficient output

Use inferior 140mil small chip,Inferior chip easy to heat after long-time working serious, and will damaged the machine

ASEMI uses laser marking, environmentally friendly, non-fading, and prevents refurbishment

Inferior and easy to drop word will pullute PCB board,and also exist a problem of malicious renovation

ASEMI uses a high-purity oxygen-free copper frame and pins, with good electrical conductivity and high strength of thickened pins

Ordinary steel is easy to be oxidize and virtual weld, the strength is low then easy to break

The ASEMI factory uses Jianding and Guankui high-precision equipment to test 18 key electrical data simultaneously

Other equipment has low precision, the electrical parameter detection is not strict, and the quality consistency is poor

APPLICATION

Industrial equipment

Led lamps and lanterns

Induction cooker

Electric welding machine

Notebook power

Automobile industry
